NETWORK
- Technology – GSM / CDMA / HSPA / EVDO / LTE / 5G
- 2G bands – GSM 850 / 900 / 1800 / 1900 – SIM 1 & SIM 2 (dual-SIM) CDMA 800 / 1900
- 3G bands – HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 CDMA2000 1xEV-DO
- 4G bands – 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 66 – A2633, A2634, A2635 1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 66, 71 – A2482, A2631
- 5G bands – 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 29, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79 Sub6/mmWave – A2633 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 29, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave – A2482 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 29, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79 SA/NSA/Sub6 – A2631 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 38, 40, 41, 48, 66, 77, 78, 79 SA/NSA/Sub6 – A2634, A2635
- Speed – HSPA 42.2/5.76 Mbps, LTE-A, 5G, EV-DO Rev.A 3.1 Mbps
LAUNCH
- Announced – 2021, September 14
- Status – Available. Released 2021, September 24
BODY
- Dimensions – 146.7 x 71.5 x 7.7 mm (5.78 x 2.81 x 0.30 in)
- Weight – 174 g (6.14 oz)
- Build – Glass front (Gorilla Glass), glass back (Gorilla Glass), aluminum frame
- SIM – Single SIM (Nano-SIM and/or eSIM) or Dual SIM (Nano-SIM, dual stand-by) IP68 dust/water resistant (up to 6m for 30 mins)
- Apple Pay (Visa, MasterCard, AMEX certified)
DISPLAY
- Type – Super Retina XDR OLED, HDR10, Dolby Vision, 800 nits (HBM), 1200 nits (peak)
- Size – 6.1 inches, 90.2 cm2 (~86.0% screen-to-body ratio)
- Resolution – 1170 x 2532 pixels, 19.5:9 ratio (~460 ppi density)
- Protection – Scratch-resistant ceramic glass, oleophobic coating Wide color gamut True-tone
PLATFORM
- OS – iOS 15, upgradable to iOS 15.4
- Chipset – Apple A15 Bionic (5 nm)
- CPU – Hexa-core (2×3.22 GHz Avalanche + 4xX.X GHz Blizzard)
- GPU – Apple GPU (4-core graphics)
MEMORY
- Internal – 128GB 4GB RAM NVMe
MAIN CAMERA
- Dual – 12 MP, f/1.6, 26mm (wide), 1.7µm, dual pixel PDAF, sensor-shift OIS 12 MP, f/2.4, 120˚, 13mm (ultrawide)
- Features – Dual-LED dual-tone flash, HDR (photo/panorama)
- Video – 4K@24/30/60fps, 1080p@30/60/120/240fps, HDR, Dolby Vision HDR (up to 60fps), stereo sound rec.
SELFIE CAMERA
- Dual – 12 MP, f/2.2, 23mm (wide), 1/3.6″ SL 3D, (depth/biometrics sensor)
- Features – HDR
- Video – 4K@24/25/30/60fps, 1080p@30/60/120fps, gyro-EIS
SOUND
- Loudspeaker – Yes, with stereo speakers
COMMS
- WLAN – Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, hotspot
- Bluetooth – 5.0, A2DP, LE
- GPS – Yes, with A-GPS, GLONASS, GALILEO, BDS, QZSS
- NFC – Yes
- USB – Lightning, USB 2.0
MORE FEATURES
- Sensors – Face ID, accelerometer, gyro, proximity, compass, barometer Ultra Wideband (UWB) support
BATTERY
- Type – Li-Ion 3240 mAh, non-removable (12.41 Wh)
- Charging – Fast charging (23W, unofficial rating), 50% in 30 min (advertised)
- USB Power Delivery 2.0
- MagSafe wireless charging 15W
- Qi magnetic fast wireless charging 7.5W
