ENERAL
-
Packaged Quantity1
 -
Platform TechnologyIntel vPro Technology
 -
Embedded SecurityTrusted Platform Module (TPM 1.2) Security Chip
 -
Operating SystemMicrosoft Windows 7 Professional 64-bit Edition (available through downgrade rights from Windows 8.1 Pro 64-bit) + Windows 8.1 Pro 64-bit License
 -
Preinstalled OSWindows 7
 -
ManufacturerLenovo

PROCESSOR / CHIPSET
-
CPUIntel Core i5 (4th Gen) 4340M / 2.9 GHz
 -
Max Turbo Speed3.8 GHz
 -
Number of CoresQuad-Core
 -
Cache6 MB
 -
64-bit ComputingYes
 -
Chipset TypeIntel QM87
 -
FeaturesHyper-Threading Technology, Intel Turbo Boost Technology 2.0, integrated memory controller

CACHE MEMORY
-
Installed Size6 MB

RAM
-
Memory Speed1600 MHz
 -
Memory Specification CompliancePC3L-12800
 -
Configuration Features1 x 4 GB
 -
TechnologyDDR3L SDRAM
 -
Installed Size4 GB
 -
Rated Memory Speed1600 MHz

STORAGE
-
InterfaceSerial ATA-600
 -
SSD CacheOptional (M.2)
 -
Optical DriveDVD-Writer removable

MEMORY
-
RAM8 GB (1 x8 GB)
 -
Max Supported Size32 GB
 -
TechnologyDDR3L SDRAM
 -
Speed1600 MHz / PC3L-12800
 -
Form FactorSO-DIMM 204-pin
 -
Slots Qty4
 -
Empty Slots3

DISPLAY
-
LCD Backlight TechnologyLED backlight
 -
Widescreen DisplayYes
 -
Image Aspect Ratio16:9
 -
Monitor Featuresanti-glare
 -
TypeLED
 -
Diagonal Size (metric)39.6 cm
 -
Display Resolution AbbreviationFull HD

HARD DRIVE
-
TypeHDD
 -
Capacity256 GB
 -
Hard Drive FeatureseDrive

AUDIO & VIDEO
-
Multi-GPU Configuration1 single GPU card / integrated GPU
 -
Graphics ProcessorNVIDIA Quadro K1100M / Intel HD Graphics 4600
 -
Video System FeaturesNVIDIA Optimus
 -
Integrated WebcamYes
 -
SoundStereo speakers, two microphones
 -
Audio CodecRealtek ALC3232

INPUT
-
TypeTrackPoint, UltraNav, keyboard
 -
Featuresmulti-touch touchpad, spill-resistant

COMMUNICATIONS
-
Wireless Protocol802.11a/b/g/n/ac, Bluetooth 4.0
 -
Wireless ControllerIntel Dual Band Wireless-AC 7260 – M.2 Card
 -
Wired ProtocolGigabit Ethernet

WIRELESS BROADBAND (WWAN)
-
GenerationWWAN upgradable

OPTICAL STORAGE
-
Drive TypeDVD-Writer
 -
TypeDVD-Writer
 -
Form Factorremovable

PROCESSOR
-
CPU TypeCore i5
 -
Processor Numberi5-4340M
 -
Generation4
 -
ManufacturerIntel
 -
Clock Speed2.8 GHz

CARD READER
-
Type4 in 1 card reader
 -
Supported Flash MemoryMultiMediaCard, SD Memory Card, SDHC Memory Card, SDXC Memory Card, SDXC UHS-II Memory Card

BATTERY
-
Technology9-cell lithium ion
 -
Capacity99.9 Wh
 -
Cells9-cell
 -
Technologylithium ion
 -
Run Time (Up To)11.1 hour(s)

AC ADAPTER
-
InputAC 120/230 V (50/60 Hz)
 -
Output170 Watt

CONNECTIONS & EXPANSION
-
Expansion Bays1 x Ultrabay
 -
Slots1 x ExpressCard/34 (1 free)
 -
Interfaces2 x USB 3.0
2 x USB 2.0
Mini DisplayPort/Thunderbolt combo
VGA
LAN
Headphone/microphone combo jack
Dock -
Memory Card Reader4 in 1 (SD Card, MultiMediaCard, SDHC Card, SDXC Card, SDXC UHS-II Card)

HEADER
-
BrandLenovo
 -
Product LineLenovo ThinkPad W541
 -
Model20EF
 -
LocalizationEnglish
 -
Packaged Quantity1
 -
CompatibilityPC

NETWORKING
-
Data Link ProtocolBluetooth 4.0, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
 -
Interface (Bus) TypeM.2 Card
 -
Ethernet Controller(s)Intel I217-LM
 -
Wireless NICIntel Dual Band Wireless-AC 7260

MISCELLANEOUS
-
Case Materialglass-fiber reinforced plastic
 -
SecurityTrusted Platform Module (TPM 1.2) Security Chip, fingerprint reader
 -
Features1 USB 2.0 (Always On), Intel Active Management Technology (iAMT), ThinkEngine, administrator password, hard drive password, power-on password
 -
Compliant StandardsGREENGUARD, RoHS
 -
Included Accessoriespower adapter
 -
Manufacturer Selling ProgramTopSeller
 -
Theft/Intrusion Protectionsecurity lock slot (cable lock sold separately)
 -
Security Slot TypeKensington security slot

MONITOR
-
Diagonal Size15.6 in

SYSTEM
-
Platform TechnologyIntel vPro Technology
 -
Notebook Typenotebook
 -
PlatformWindows
 -
Hard Drive Capacity250 GB
 -
DockableYes
 -
Embedded SecurityTrusted Platform Module (TPM 1.2) Security Chip
 -
Security Devicesfingerprint reader
